Infusion pump

Infusion Pump Yk-IP3

Infusion speed Infusion volume accuracy error Infusion volume preset blocking pressure KVO voltage Power consumption Built-in battery working time Dimensions weight Safety classification waterproof level working environment storage environment 3 inch monochrome LCD display 1ml/h – 1200ml/h can be incremented or decreased by 0.1ml/h ±5% (ordinary infusion set) 0.1ml – 9999.9ml can be decreased in increments of 0.1ml High: 110kpa Medium: 80kpa Bottom: 40kpa” 1ml/h – 5ml/h can be decreased in increments of 1ml/h Not more than 35VA 90*205*151 1.5kg Class I, type BF general equipment with internal power supply IPX1 d.c11.1V not less than 2000mA,not less than 12 hours Power supply voltage AC 100~240V AC, power frequency: 50/60Hz battery input 9.5V-12.6V Ambient temperature: 10~30℃ Relative humidity: 30%~75% Atmospheric pressure: 860hPa–1060hPa The infusion pump should work in an environment where there is no strong shock and vibration, water and other fluids cannot invade the inside of the device, and there is no corrosive gas around. The packaged infusion pump should not exceed 93% (no condensation), and no corrosive gas will pass through a good room, and the indoor temperature conditions are: -20℃~+55℃
